Blackmagic Design Videohub 10x10 12G Zero-Latency Video Router

Blackmagic Design Videohub 10x10 12G Zero-Latency Video Router

SKU: #VHUBSMAS12G1010

Dhs. 5,699.00
Dhs. 5,699.00
Sale Sold out
Inclusive of VAT
Shipping calculated at checkout.

In stock

Key Features

  • Zero-Latency Routing Switcher
  • 10 x 12G-SDI Inputs/10 x 12G-SDI Outputs
  • Supports Up to DCI 4K60 Video
  • Combines SD, HD, UHD 4K & DCI 4K Video
View full details
  • Description
  • Technical Specification
  • In the Box
  • Delivery & Shipping Policy

Blackmagic Design 10x10

Support a mix of multiple video formats using the Videohub 10x10 12G Zero-Latency Video Router from Blackmagic Design. This advanced router provides 10 12G-SDI inputs and ten 12G-SDI outputs for routing any combination of SD, HD, UHD 4K, and DCI 4K video. The Videohub 10x10 12G centralizes all your SDI cables in one hub, enabling you to connect any video input to any video output or even a single video input to multiple video outputs while eliminating clusters of cables and the need for complex diagrams. This versatile unit can be used with multiple HyperDeck recorders for redundant mastering to route video to multiple streaming processors for all your broadcast platforms or add extra inputs to an ATEM switcher.

Blackmagic Design 10x10 Specs

• Switching Type: Pushbutton, Software

• Processing Resolution: DCI 4K at 60

• Color Processing:

 • 8-Bit 4:2:2

 • 10-Bit 4:2:2

 • 12-Bit 4:4:4

• Audio Processing: 48 kHz / 24-Bit

Input

• Video Inputs: 10x BNC (12G-SDI)

• Input Video Format:

 SDI (10/12-Bit 4:4:4 RGB, YUV)

  • DCI 4K up to 30 fps

  • UHD 4K up to 30 fps

  • DCI 2K up to 60 fps

  • DCI 2KPsF up to 30 fps

  • 1080p up to 60 fps

  • 1080PsF up to 30 fps

  • 1080i up to 60 fps

 SDI (10-Bit 4:2:2 RGB, YUV)

  • DCI 4K up to 60 fps

  • UHD 4K up to 60 fps

  • DCI 2K up to 60 fps

  • DCI 2KPsF up to 30 fps

  • 1080p up to 60 fps

  • 1080PsF up to 30 fps

  • 1080i up to 60 fps

  • 720p at 50/59.94/60 fps

  • 576i / 625 lines at 50 fps

  • 480i / 525 lines at 59.94 fps

• Embedded Audio Input: SDI

Output

• Video Outputs: 10x BNC (12G-SDI)

• Output Video Format:

 SDI (10/12-Bit 4:4:4 RGB, YUV)

  • DCI 4K up to 30 fps

  • UHD 4K up to 30 fps

  • DCI 2K up to 60 fps

  • DCI 2KPsF up to 30 fps

  • 1080p up to 60 fps

  • 1080PsF up to 30 fps

  • 1080i up to 60 fps

 SDI (10-Bit 4:2:2 RGB, YUV)

  • DCI 4K up to 60 fps

  • UHD 4K up to 60 fps

  • DCI 2K up to 60 fps

  • DCI 2KPsF up to 30 fps

  • 1080p up to 60 fps

  • 1080PsF up to 30 fps

  • 1080i up to 60 fps

  • 720p at 50/59.94/60 fps

  • 576i / 625 lines at 50 fps

  • 480i / 525 lines at 59.94 fps

• Embedded Audio Output: SDI

Connectivity

• Other I/O:

 • 1x RJ45 LAN

 • 1x USB-C

• Video Standard Compliance:

 • SMPTE 259M/292M/296M/372M/424M/425M-A/425M-B

 • ST-2081-1 / ST-2081-10 / ST-2082-10

 • ITU-R BT.601 / BT.656

Display

• Display Size: 2.2"

Hardware & Compatibility

• OS Compatibility: macOS 12 or Later / Windows 10 or Later

• Wireless: No

Power

• Power I/O: 1x IEC C14 (100 to 240 VAC) Input

• Power Consumption: 20.8 W

General

• Operating Conditions: 32 to 72°F / 0 to 40°C, up to 90% Humidity

• Storage Conditions: -4 to 140°F / -20 to 60°C

• Rack Form Factor: 1U

• Dimensions: 19 x 9.3 x 1.74" / 48.3 x 23.6 x 4.42 cm

• Weight: 6.64 lb / 3.01 kg

Packaging Info

• Package Weight: 7.96 lb

• Box Dimensions (LxWxH): 20.6 x 11.9 x 3.5"
