Yamaha

Yamaha MG10XU 10-Input Mixer with Built-In FX and 2-In/2-Out USB Interface

Yamaha MG10XU 10-Input Mixer with Built-In FX and 2-In/2-Out USB Interface

SKU: MG10XU

Dhs. 1,149.00
Dhs. 1,149.00
Sale Sold out
Inclusive of VAT
Shipping calculated at checkout.

Low stock: 1 left
Badge

Key Features

  • 4 x Mic/Line Combo Inputs
  • 6 x 1/4" Line Inputs
  • 2-In/2-Out USB up to 24-Bit / 192 kHz
  • Built-In FX with 24 Presets
  • XLR and TRS 1/4" Stereo Outs
  • TRS Monitor Outs
  • "D-PRE" Mic Preamps with 48V Phantom
  • HPF & 3-Band EQ on Mic/Line Inputs
  • 1/4" Headphone Output with Level Control
  • USB Works with PC, Mac, and iOS
View full details
  • Description
  • Technical Specification
  • In the Box
  • Delivery & Shipping Policy

Yamaha MG10XU

The MG10XU from Yamaha is a compact ten-input mixer with built-in effects for performances, lectures, recordings, and similar applications. The mixer features four mic/line combo inputs with D-PRE mic preamps as well as six 1/4" line inputs with stereo level controls. It also features USB connectivity and is capable of providing two channels in and two channels out to your computer at up to 24-bit / 192 kHz, ideal for recording live performances, demos, and more.

Each of the four mic/line inputs is equipped with a 3-band EQ, pan control, and a high-pass filter. The four D-PRE mic preamps feature an inverted Darlington circuit and switchable 48V phantom power for use with dynamic and condenser microphones. They also each feature 26 dB attenuation switches for recording loud sound sources such as guitar amplifiers.

The MG10XU mixer has stereo XLR and TRS outs for connecting to your PA system or monitor speakers. It also has a 1/4" headphone output with level control for personal monitoring as well as additional TRS 1/4" stereo monitor outs for sending to powered speakers, amplifiers, or devices such as digital recorders.

Each of the MG10XU's channels feature a dedicated FX bus send level and there are 24 effects presets to choose from. The overall level of the FX bus is controlled by the dedicated FX return level control. Providing reverbs, delays, phaser, flanger, chorus, tremolo, auto-wah, distortion, and more, these effects can be used to help vocals and instruments sit better in your mix.

Yamaha MG10XU Specs

• Built-in Effects

 • SPX Algorithm: 24 Program

• Phantom Power

 • +48 V Switchable, Channels 1 - 4

• Digital I/O

 • USB: USB Audio Class 2.0 Compliant

 • Sampling Frequency: Max 192 kHz

 • Bit Depth: 24-Bit

• Input Channels

 • 4 x Mono [Mic/Line]

 • 3 x Stereo [Line]

• Output Channels

 • 2 x Stereo Out

 • 1 x Monitor Out

 • 1 x Headphone Out

 • 1 x FX Out

• Bus

 • Stereo: 1

 • AUX[FX]: 1

• Pad

 • 26 dB (Mono Channels)

• HPF

 • 80 Hz, 12 dB/Oct (Mono Channels)

• Compressor

 • Threshold: +22 dBu to -8 dBu

 • Ratio: 1:1 to 4:1

 • Output Level: 0 dB to 7 dB

 • Attack Time: Approx 25 msec

 • Release Time: Approx 300 msec

• Equalizer

 • EQ High Gain: +15 dB/-15 dB, Frequency: 10 kHz Shelving

 • EQ Mid Gain: +15 dB/-15 dB, Frequency: 2.5 kHz Peaking

 • EQ Low Gain: +15 dB/-15 dB, Frequency: 100 Hz Shelving

• LED

 • Peak LED Turns On When Post EQ Signal Reaches 3 dB Below Clipping

• Level Metering

 • 2 x 7-Segment LED Meter [PEAK, +10, +6, 0, -6, -10, -20 dB]

• Total Harmonic Distortion

 • 0.02% @ +14 dBu (20 Hz to 20 kHz), GAIN Knob: Min

 • 0.003% @ +24 dBu (1 kHz), GAIN Knob: Min

• Frequency Response

 • +0.5 dB/-1.0 dB (20 Hz to 48 kHz), Refer to the Nominal Output Level @ 1 kHz, GAIN Knob: Min

• Equivalent Input Noise

 • -128 dBu (Mono Input Channel, Rs: 150 Ohms, GAIN Knob: Max)

• Residual Output Noise

 • -102 dBu (STEREO OUT, STEREO LEVEL Knob: Min)

• Crosstalk

 • -83 dB

• Power Requirement

 • PA-10 (AC 38 VCT, 0.62A) or Equivalent Recommended by Yamaha

• Power Consumption

 • 22.9 W

• Operating Temperature

 • 32 to 104˚F / 0 to 40˚C

• Dimensions

 • 9.6 x 2.8 x 11.6" / 244 x 71 x 294 mm

• Net Weight

 • 4.63 lb / 2.1 kg

• Packaging Info

 • Package Weight: 7.61 lb

 • Box Dimensions (LxWxH): 14.3 x 6.2 x 5.3"

  • Yamaha MG10XU 10-Input Mixer with Built-In FX and 2-In/2-Out USB Interface
  • Power Supply
  •  Limited 1-Year Manufacturer Warranty
