Yamaha

Yamaha PX3 Stereo Power Amplifier (300W at 8 Ohms)

Yamaha PX3 Stereo Power Amplifier (300W at 8 Ohms)

SKU: PX3

Dhs. 2,249.00
Dhs. 2,249.00
Sale Sold out
Inclusive of VAT
Shipping calculated at checkout.

Low stock: 1 left
Badge

Key Features

  • 300W per Channel at 8 Ohms
  • Efficient Class-D Amplifier
  • Custom LSI Chip with PLL Technology
  • Power Boost Mode
  • Digital Routing of Inputs & Outputs
  • XLR, 1/4", SpeakON & Binding Post
  • PEQ, Crossover, Filters, Delay
  • D-Contour Multi-Band Dynamic Processing
View full details
  • Description
  • Technical Specification
  • In the Box
  • Delivery & Shipping Policy

Yamaha PX3

The Yamaha PX3 Stereo Power Amplifier delivers 300W at 8 Ohms in a lightweight chassis and is suitable for a wide variety of sound-reinforcement applications. Part of the company's PX Series of power amplifiers, it features a Class-D engine with a single custom LSI chip, and uses PLL technology for higher efficiency and lower noise. The Power-Boost mode combines the power output from two channels into one, achieving significantly higher single-channel power levels (the number of channels available is then halved).

The on-board DSP functions include a PEQ, a delay, a crossover, and a limiter. They also allow for detailed configuration of parameters such as input & output routing, input sensitivity, amp gain, and speaker impedance. The D-Control multi-band dynamic processor delivers a clear and consistent sound at any output level by shaping the frequency response of each speaker for either front-of-house or monitor configurations.

The Configuration Wizard helps save time during setup by assigning optimized speaker settings that match your system configuration. It can be used in basic mode for quick setup or advanced mode for more precise control over DSP parameters. You can store up to eight presets, which can be saved to a USB drive for use with other amplifiers and setups.

For secure operation, the panel-locking function ensures that your settings remain safe. With its sturdy frame and carrying handle, the PX3 is built to withstand extended road use.

Yamaha PX3 Specs

• Number of Channels: 2

• Amplifier Power Rating @ 8 Ohms: 300 W per Channel

• Amplifier Power Rating @ 8 Ohms (Bridged): 600 W

• Amplifier Power Rating @ 4 Ohms: 500 W per Channel

• Amplifier Power Rating @ 4 Ohms (Bridged): 1000 W

• Amplifier Power Rating @ 2 Ohms: 300 W per Channel

• Amplifier Class: Class-D

• Frequency Response: 20 Hz to 20 kHz ±1 dB (at 1 W, 8 Ohms)

• Input Impedance (Unbalanced): 10 Kilohms

• Input Impedance (Balanced): 20 Kilohms

• Max Gain: 35.1 dB (at 8 Ohms)

• Max Input Level: +24 dBu

• Signal-to-Noise Ratio (SNR): 100 dB

• THD+N @ 1 kHz, 10 W: 0.1%

• THD+N @ 1 kHz, 1/2 Power: 0.3%

• Crosstalk: < -60 dB

• Sample Rate: 48 kHz

• A/D Conversion: 24-Bit, 128x Oversampling

• D/A Conversion: 24-Bit, 128x Oversampling

• Audio Delay: Adjustable up to 74 ms

• EQ: 6-Band Parametric EQ

• High-Pass Filter: 20 Hz to 20 kHz

• Low-Pass Filter: 20 Hz to 20 kHz

• Limiting: Yes

• Analog Inputs: 2x XLR 3-Pin

• Analog Inputs: 2x 1/4" TRS

• Analog Outputs: 2x speakON NL4

• Analog Outputs: 2x Binding Post Pair

• Analog Outputs: 2x 1/4" TS

• USB I/O: 1x USB-A 2.0

• AC Input Power: 120 VAC, 60 Hz

• Power Consumption @ 4 Ohms (1/8 Power): 160 W

• Power Consumption (Idle): 55 W

• Cooling: 2x Fan (Variable Speed)

• Operating Temperature: 32 to 104°F / 0 to 40°C

• Storage Temperature: -4 to 140°F / 0 to 40°C

• Dimensions: 18.9 x 3.5 x 15.2" / 480.0 x 88.0 x 387.4 mm

• Weight: 15.2 lb / 6.9 kg

• Package Weight: 19.5 lb

• Box Dimensions (LxWxH): 21.75 x 21.75 x 7.5"

  • Yamaha PX3 Stereo Power Amplifier (300W at 8 Ohms)
  • AC Power Cord
  • USB Cap
  •  Limited 3-Year Manufacturer Warranty
