Allen & Heath ZED-10 Multipurpose Mini Mixer

Allen & Heath ZED-10 Multipurpose Mini Mixer

SKU: AH-ZED10

Dhs. 1,099.00
Dhs. 1,099.00
Sale Sold out
Inclusive of VAT
Shipping calculated at checkout.

Low stock: 1 left
Badge

Key Features

  • Portable Mixer for Live & Studio Mixing
  • 4 x Mic/Line Inputs
  • 2 x Hi-Z Class-A FET Guitar Inputs
  • Two Stereo Line Inputs
  • USB Digital Audio Interface
  • 3-band EQs with MusiQ Technology
  • Aux and FX Sends
  • Monitoring Section with Headphone Out
  • Separate Monitor Speaker Output
  • 12-Bar Meters, Illuminated PFL Indicator
View full details
  • Description
  • Technical Specification
  • In the Box
  • Delivery & Shipping Policy

Allen & Heath ZED-10

The multipurpose Allen & Heath ZED-10 mixer combines four mic/line inputs, two Hi-Z guitar inputs, two stereo inputs for effect returns and portable music players or keyboards, and a USB digital audio interface compatible with Mac and Windows computers—in a compact and portable package small enough for carrying to your gig, whether recording live or in the studio. It is also an excellent choice for small PA and AV rentals, and for installation in hotels, small churches, and schools.

Channels 1 through 4 feature XLR mic inputs and low-noise preamps with 60 dB of gain. Channels 1 & 2 also offer balanced/unbalanced line inputs while 3 & 4 feature Hi-Z inputs with Class-A FET circuits and 26 dB boost switches, designed to add tube-like warmth to your guitar and other instruments. All four mono channels are equipped with responsive, 3-band swept-mid EQs, which utilize MusiQ technology to optimize the Q factor according to the amount of boost or attenuation.

The ZED-10 offers a set of FX and aux sends, 48V microphone phantom power, XLR main stereo outputs with inserts, a comprehensive monitoring section with a headphone output, and a separate monitor speaker output.

Allen & Heath ZED-10 Specs

Configuration

• Type: Analog Mixer

• Number of Channels: 10 (8 Mono / 2 Stereo)

• Number of Mic Preamps: 4

• Analog Output Channels:

 – 1x Stereo Master Output

 – 1x Stereo Control Room / Monitor Output

 – 1x Stereo Tape / Record Output

 – 1x Mono Aux Send Output

 – 1x Mono FX Send Output

 – 1x Stereo Headphone Output

• Mix Routing: Main Mix / Bus / Subgroup

• Built-In Effects: None

• Rack Mountable: No

Faders & Level Adjustment

• 7x Channel Knob

• 1x Master Fader

Meters

• 8-Segment LED

EQ

• Mono Channels: 3-Band EQ

• Stereo Channels: 2-Band EQ

• Graphic EQ: No

Signal Processing

• Dynamic Processing: None

• Solo / Mute: No

Digital Audio

• Sample Rates: 32 / 44.1 / 48 kHz

• Bit Depth: 16-Bit

Performance

• Frequency Response:

 – Line Input to Main Output: 10 Hz to 25 kHz +0.5/-1 dB (Unity Gain)

 – Mic Input to Main Output: 10 Hz to 30 kHz +0.5/-1 dB (30 dB Gain)

 – Stereo Input to Main Output: 10 Hz to 30 kHz +0.5/-1 dB

• Max Input Level:

 – XLR Input: +11 dBu (Mono)

 – 1/4" Line Input: +31 dBu (Mono)

 – 1/4" / RCA Input: +15 dB (Stereo)

• Noise Floor: Main Output: -96 dBu

• THD+N:

 – Hi-Z Input to Main Output: 0.015% at Unity Gain

 – Line Input to Main Output: 0.003% at Unity Gain

 – Mic Input to Main Output: 0.002% at +10 dB Gain, 0.01% at +30 dB Gain

 – Stereo Line Input to Main Output: 0.002% at Unity Gain

Connectivity

Analog Inputs

• 2x 1/4" TRS Balanced/Unbalanced Line Input

• 4x 1/4" TRS Balanced/Unbalanced Line Input (2 Stereo Pairs)

• 1x Stereo RCA Unbalanced Line Input

• 2x 1/4" TRS Main Insert

• 2x 1/4" TS Hi-Z Input

• 4x XLR 3-Pin Balanced Mic Input

Analog Outputs

• 1x 1/4" FX Send (Post-Fader)

• 1x 1/4" Aux Send (Pre-Fader)

• 1x 1/4" TRS Headphone Output

• 1x Stereo RCA Monitor Output

• 1x Stereo RCA Tape Output

• 2x XLR 3-Pin Balanced Main Output

Other I/O

• Phantom Power: +48 V

• USB I/O: 1x USB-B 1.1 (2x Input / 2x Output)

• MIDI I/O: None

• Digital I/O: None

• Wireless: No

Compatibility

• OS Compatibility: Windows, macOS

Power

• AC Input Power: 100 to 240 VAC, 50 / 60 Hz

• Power Supply Output: Included

Physical

• Rack Mountable: No

• Dimensions (W x D x H): 13.2 x 3.7 x 10.8" / 336 x 95 x 275 mm

• Weight: 7 lb / 3.2 kg

Packaging Info

• Package Weight: 9.25 lb

• Box Dimensions (LxWxH): 15.7 x 12.3 x 5.9"

  • Allen & Heath ZED-10 Multipurpose Mini Mixer
  • Power Cord
  •  Limited 1-Year Manufacturer Warranty
